5.2 Appendix 2 - Technical Specifications - Free-E
Ordering Codes
DOMM 054739
Voltage / Current
Input Voltage Range 215V to 255Vac, 50/60Hz
Maximum continuous AC output current at 210 V 14.2A +/-1%
Maximum continuous AC output current at 230 V 13.0A +/-1%
Maximum continuous AC output current at 254 V 11.8A +/-1%
16A +/-1%
Maximum output over current protection
Maximum input overvoltage protection 260 Vac
Cooling conceptElectrical Forced Air Convection
Relay output ratings
16A…... 250Vac
0.9x … 1.0
Range of output power factor
0.99
Nominal Power factor
24 - 230Vac
External Input voltage range
98.2%
Wireless Technology
Radio Technology Dimplex GFSK
Radio Frequency 868 MHz ISM Band
Channels 4 Channels (1-4)
Max Tx Power +13dBm
Rx Sensitivity -105dBm@25Kbps
WiFi IEEE 802.11 b/g/n
Wireless Range Indoor Range up to 50m
Outdoor Range up to 300m (direct line of sight)
Standby Power
Power Consumption 10 Watt
Physical
Dimensions (LxWxH) 316 x 279 x 110 mm
Certifications
CE Fully EMC Compliant
Weight 3.7kg
Mounting Wall Mounting Flanges
Enclosure V0 Polycarbonate
Operating Temperature -20°C to +45°C
Operating Humidity up to 85% (non-condensing)
Peak Free-E efficiency
