8 www.nectreusa.com
Installation
positioning the stove.
WARNING: Do not install this stove in a bedroom.
Outside Air Requirements
airtight compared to older homes. Airtightness makes a house more susceptible to negative pressure
when combusted air is exhausted through the chimney. Large extraction fans can cause extreme
negative pressure which can lead to air starvation, which negatively impacts the performance of the
stove.
To prevent air starvation, slightly open a nearby window to allow fresh air to enter the room. In
extremely cold regions, opening a window may not be feasible, or icing may block the required
ventilation. Installation of an outside air duct with a rodent screen and rain hood will be required to
apply in certain localities.
Floor Protector (Hearth)
are considered to be combustible materials, with the exception of gypsum.
side curved edges and edge of the rear panel. For installations with horizontal rear connector, the
Floor Protector
US Canada
G N/A 8" (203 mm)
H 5" (127 mm) 8" (203 mm)
I 16" (406 mm) 18" (457 mm)
H
G
I
ADJACENT WALL
MUR ADJACENT
BACK WALL
MUR ARRIÈRE
ADJACENT WALL
MUR ADJACENT
B
D
E
F
H
* FOR REAR HORIZONTAL VENTS
EXTEND PROTECTION UNDER AND
2" EITHER SIDE OF VENT
Figure 2
