- 23 -
15. The third row of energy cells is positioned in a manner similar to the first row. Again be careful not to damage or
dislodge the element. (Fig. 15)
16. Fit the fourth row of energy cells above the third row in the upside position. Again, the first energy cell should
be positioned firmly against the right-hand insulation, and the second energy cell should be positioned firmly
against the left-hand insulation. (Fig. 16). Repeat for the fifth and sixth rows of energy cells built around the third
element to complete the core build.
17. Remember the top row of energy cells must be fitted upside down. (Fig. 17)
Check that all the energy cells are secure and evenly located.
18. Close the core by refitting the inner front panel complete with insulation, starting at position and working
clockwise. (Fig. 18)
Ensure the bottom tabs are located inside the chassis and that the screws are tightly secured down each edge.
Ensure the screws retaining the heater to the wall are fully tightened, once the energy retention cells are fully loaded.
(Fig. 7, page 15)
IMPORTANT
Double check all mains connections are secure and excess cable is restrained and not in contact with any of
the heater casing.
ON NO ACCOUNT SHOULD ANY SURPLUS CABLE BE PUSHED INSIDE OR BEHIND THE HEATER.
Once installed DO NOT attempt to reposition the heater without first unloading the energy cells.
Reassembly
To replace the bottom grille and front panel, reverse steps Figs. 4, 5 & 6 (page 13) of these instructions under the
section headed Preparation.
Ensure all fixings are secure.
