Dimplex Quantum series Installation Manual

- 9 -
All Models
Controls
Digitally controlled, Electronic Thermostat accurate to (±0.2°C).
Timer modes:
7 Day Programmable User Timer, Out All Day, Home All Day
Continuous heat modes:
Frost Protect
Additional Modes:
Away, Boost, Setback
Controller UI
• Graphical display with RGB backlight
• Tactile buttons with audio feedback
• User replaceable battery (Coin-Type)
• Open window detection, Adaptive Start, Advance Time Period
• Wide SP range (7-30°C)
• Automatic Charge Control
• History / Reporting Screens
• Boost Mode, User Adjustable
• Heat Demand % Adjustment
• Child Lock & Heater Lock (PIN-based)
Safety
Electronic overheat protection.
Additional electromechanical overheat protection.
LVD and EMC compliance.
IP Rating IPX4
Battery 3.3V coin cell battery to backup real time clock. Battery life > 5 years.
Supply 1/N/1/N/PE ~230-240V (Peak + O Peak) 230-240V / 50Hz Class II
Colour / Finish
Trac White (RAL 9016),
Grille RAL7035
Storage Core High-density bonded magnetite energy cells
Approvals CE & BEAB
Guarantee 2 Years. 10 Years extended available with registration.
Country of Origin United Kingdom
Manufacturer
Glen Dimplex Heating & Ventilation
(GDC Group Ltd)

Dimplex Quantum series Specifications

General

Operation	Quiet operation
Adjustable Thermostat	Yes
Timer	Yes
Weight	Varies by model
Dimensions	Varies by model
Color Options	White
Energy Efficiency	High
Programming	24/7 Programmable
Safety Features	Overheat protection
Voltage	230-240V
Remote Control	Via smartphone app (depending on model)
