9 Technical data
Ambient conditions
Ambient temperature (operation)
-20 to +55°C DIN IEC 60068-2-3
Ambient temperature (storage)
-40 to +85°C DIN IEC 60068-2-3
Maximum altitude
max. 2000m (above sea level)
Vibration resistance 3 axis
Sinus 10–55Hz, 0,35mm, 10 cycles, 1 octave/min
Air and creepage distances
DIN EN 50178, safe isolation
Protection class
Installation in a closed cabinet, min. IP54
Input data
Operating voltage UB
24V DC -15 % / +10 %, reverse protection
Current draw at 24V DC
typ. 80mA
Current draw at L1, L2, L3
0,35mA at 690V AC
Input voltage at L1, L2, L3
90 to 690V AC
Input frequency at L1, L2, L3
≤ 600 Hz
Switching hysteresis
10%
Power consumption at A1/ A2
typ. 1,9W
Status display
4 x LED 2-color
Protection wiring
Overvoltage/ inverse polarity protection
Output data
Contact type
2 enabling NO-contacts
Contact material
AgSnO
2
Operating voltage
24V DC / 230V AC
Minimum switching current
3 mA/ 24V DC
Maximum switching current
6A / 24V DC/ 230V AC
Short-circuit strength
1000A SCPD 6A gL/gG
Mechanical life
10
7
switching cycles
Reaction time
Up to 30 Hz: 1 period (reciprocal value of the set frequency) + 10ms
Over 30 Hz: 3 x 1 period + 10ms
Output fuse
6 A gL/gG
B10d values acc. to
DIN EN 61810-2-1, 01.2012
AC15: 5A/230V AC, >2x10
5
,
AC1: 6A/230V AC, >2x10
5
DC13: 4A/24V DC, >3x10
5
DC1: 6A/ 24V DC, >7x10
5
switching cycles
Total current 13-14 and 23-24
with parallel connection: 6A
with serial connection: 3A
Outputs O1, O2
≤ 100mA( UB-1V) shot-circuit and overload protection
General data
Nominal operating mode
100 %
Protection class
IP20
Mounting position
vertical or horizontal
Housing material/ Type
Polyamide PA not increased/ ME/ Phoenix Contact
Dimensions
B x H x T/ 22,5 x 114 x 111 mm
Degree of pollution
2
Overvoltage category
III
Connection data
Terminals/ Material
Push-in, pluggable/ PA
Screw, pluggable /PA
Number of pins
4
5
3
Rated surge voltage
4kV
2,5kV
8kV
Rated insulation voltage
320V
160V
1000V
Conductor cross-section, flexible
with wire end sleeve
0,25 - 2,5mm
2
0,25 - 1,5mm
2
0,25 - 2,5mm
2
Conductor cross section AWG
24…12
24…16
24…12
Connection wire
60/75°C Copper
Tightening torque min/max
-
-
0,5Nm/0,6Nm
