DINA DN3PD1 - Relay Load Curve; 10 Dimensions

DN3PD1
Dimensions
18 18-09-27 / 33pd02-V0743
Relay load curve
L / R = 0 ms
4
6
10
5
3
2
1
0.5
0.4
0.30.1
0.2
1000
300
10
DC Spannung / DC voltage
DC Schaltstrom (A) / DC Switching current (A)
200
100
50
40
30
20
L / R = 40 ms
ohmic load L/R = 0ms
inductive load L/R = 40ms
WARNING
Loads with high capacitive component can destroy the output contacts because the switching cur-
rent is very high.
10 Dimensions
111
114
22
.5
