DINGLI BA20ERT - Position of Least Forward Stability

Operation & Maintenance Manual Section5-Operation Instruction
Dingli Machinery
5-3
Figure 5-1 Position of Least Forward Stability
MACHINE WILL TIP OVER IN
THIS DIRECTION IF
OVERLOAD OR
OPERATED ON AN
OUT-OF-LEVEL SURFACE
TELESCOPE FULLY
EXTENDED
UPPER BOOM
HORIZONTAL
TURN 90 DEGREES AND LOWER ＆ MID BOOM LIFG BETWEEN 20 AND 30 DEGREES
