2 Cage load parameter shows the current
load in the platform.
3 Cage load parameter will show 0kg when
the load in the platform is removed
completely.
4 Cage load parameter will show 454kg
(300kg) at the moment of 454kg (300kg
when the length of the boom extended
exceeds the limit for BT30RT) being
added in the platform.
5 Continue to add load in platform, and then
the alarm will be activated when the load
is up to 525kg (350kg). Otherwise, stop to
ask for repairing.
6 The accuracy of weighting is ±10%. If
the data exceeds it, stop to calibrate it,
referring to the chapter E-7.
B-1 Transmission shaft -
lubrication of universal joints
Set the vehicle in the parking position. Make
sure no one approaches the work area.
Lubricate the universal joints by injecting
grease into the grease nipples. Repeat for all
the transmission shaft joints. Remove the
excess grease.
