OPERATOR’S MANUAL with Maintenance Information
Operating Instructions
26
Observe and Obey:
√ Common sense and planning must be
applied to control the movement of the machine
when lifting it with a crane or forklift.
√ The transport vehicle must be parked on a
level surface.
√ The transport vehicle must be secured to
prevent rolling while the machine is being
loaded.
√ Be sure the vehicle capacity, loading
surfaces and chains or straps are sufficient to
withstand the machine weight. See the serial
label for the machine weight.
√ The machine must be on a level surface or
secured before releasing the brakes.
Brake Release Operation
1 Chock the wheels to prevent the machine
from rolling.
2 Be sure the winch line is properly secured
to the drive chassis tie points and the path
is clear of all obstructions.
3 Turn the key switch to power on.
4 Pull out both ground and platform red
Emergency Stop buttons to the on position.
5 Press the brake release button release the
brakes.
After the machine is loaded:
1 Press the brake release button to reset the
brakes.
2 Push in both ground and platform red
Emergency Stop buttons to the off position.
3 Turn the key switch to the off position.
4 Chock the wheels to prevent the machine
from rolling.
