DINGLI S03-E - Page 39

OPERATOR’S MANUAL with Maintenance Information
Part Manual
37
NO.
Parts NO.
Description
Qty.
Remark
1
JCPT5007MQ-113004
Cover plate2
1
2
JCPT5007MQ-113003
Cover plate
1
3
JCPT5007MQ-113002
Plate
2
4
JCPT5007MQ-113100
Chassis
1
6
JCPT5007MQ-113001
Pedal plate
1
7
GB/T 819.2-1997
Screw M8×30
4
8
6’’ swivel wheel
1
9
GB/T 93-1987
Washer 10
8
10
GB/T 97.1-2002
Washer 10
9
11
GB/T 5782-2000
Bolt M10×45
8
12
JCPT5007MQ-113007
Lock
2
13
GB/T 70.1-2000
Screw M5×8
1
14
Pump
1
0.8kW
15
JCPT1212HD-13203
Sleeve
1
16
GB/T 70.1-2000
Screw M3×10
1
17
JCPT0630-6001
plate
1
18
JCPT1212HD-13232
Linker
1
19
JCPT1212HD-13244
Sleeve 2
1
20
GB/T 6171-2000
Nut M8×1
2
21
GB/T 97.1-2002
Washer 8
2
22
Circuit protector
1
23
GB/T 70.1-2000
Screw M10×30
2
24
JCPT1212HD-13242
Slide sleeve
1
25
GB/T 6170-2000
nut M10
1
26
JCPT1212HD-13241
Joint
1
27
JCPT1212HD-13250
Handle
1
28
GB/T 889.1-2000
Nut M6
8
29
GB/T 818-2000
Screw M4×10-H
33
30
JCPT5007MQ-113006
Plate
1
31
JCPT0630-13011
Ground Station
1
32
JCPT5007MQ-00300
Control plate 2
1
33
Circuit protector
1
34
Control modular
1
