DINGLI S03-E - Page 45

OPERATOR’S MANUAL with Maintenance Information
Part Manual
43
NO.
Parts NO.
Description
Qty.
Remark
1
JCPT5007MQ-131100
Inner 1 arm
1
2
JCPT5007MQ-131200
Out 1 arm
1
3
JCPT5007MQ-131009
Axis
14
4
JCPT5007MQ-131010
Axis
2
5
Flange
20
6
GB894.2-1986
Bead flange D20
20
7
JCPT5007MQ-131006
Safety arm
2
8
JCPT5007MQ-131007
Safety holder
2
9
GB/T 97.1-2002
Washer 6
40
10
GB/T 5783-2000
Bolt M6×20
5
11
GB/T 889.1-2000
Nut M6
20
12
JCPT5007MQ-131300
Inner 2 arm
1
13
JCPT5007MQ-131400
Out 2 arm
1
14
JCPT5007MQ-131004
Plate
2
15
JCPT5007MQ-131500
Inner 3 arm
1
16
JCPT5007MQ-131600
Out 3 arm
1
17
JCPT5007MQ-131002
slide block
4
18
JCPT5007MQ-131001
Axis
6
19
JCPT5007MQ-153100
Cylinder
1
20
JCPT5007MQ-131008
Axis
2
21
25-2023
Bearing
22
22
GB/T 5782-2000
Bolt M10×90
18
23
6x65.S
Pin
2
24
TZ-8108
Travel switch
1
25
GB/T 70.1-2000
Screw M4×10
2
26
GB/T 70.1-2000
Screw M4×30
2
27
Silencer
1
