Arm Assembly & Part List
Item Qty Part Number Description
1 1 K93-213 Load Arm Assembly No Bushes
2 3 321-000-005 2 1/2" x 8" Lift Ram 1 1/4" Top Clevis
3 2 043-000-029 1 1/4"OD 1" ID Garloch Bush
3 2 043-000-056 1 1/4"OD 1" ID Duralon Bush
4 2 043-000-032 1 1/2"OD 1 1/4" ID Galoch Bush
4 2 043-000-057 1 1/2"OD 1 1/4" ID Duralon Bush
5 2 K94-026 Clevis Pin 1 1/4" x 63mm 50mm Tag
6 2 D95036 Clevis Pin 1" x 75mm 50mm Tag
7 2 D95034 Clevis Pin 1" x 64mm 30mm Tag
8 1 K93-006 Clevis Pin 1" x 115mm 30mm Tag
9 7 132-131-000 5/16" Spring Washer
10 7 111-311-016 Hex Bolt M8x16
