Front Hydraulic Bank Setup
Item Qty Part Number Description
1 1 330-003-013 FLOW REGULATOR 950/K93 60L SFR308BP60
2 1 316-476-501 NIPPLE CR20812 1/2BSPP X 3/4’’JIC ENC-O-RING
3 3 315-477-500 ELBOW CP560814 90 M/M 1/2BSPP X 7/8JIC
4 1 316-474-700 NIPPLE ZCP10808 1/2 BSPP M/M ADJ
5 1 330-003-035 VALVE NO-RELIEF PUMP SELECTOR SD4 DCV MONOBLOCK SD
6 1 330-003-019 VALVE W/RELIEF AUXILIARY SD4 SINGLE 950/K93 SD4/1
7 1 315-474-701 ELBOW CPB530808 90 DEG M/M 1/2BSPP X 1/2 BSPT
8 1 330-003-017 One Way Flow Valve SNDR081BP05
9 1 317-474-775 TEE ZCP62080814 1/2BSPP X 7/8JIC ADJ M
10 1 344-010-002 PIPE - REMOTE TO SUB BANK - 4B D95743
11 1 REMOTE BANK HANDLE
12 1 330-003-007 CONTROL LEVER 950&K93 FLOW DIVIDER 13-064
13 1 315-757-600 ADAPTOR C461414 90 M/F 7/8 X 7/8 JIC
14 3 316-477-501 CP2-0814
15 1 PUMP SELECTOR HANDLE
To Next Page
