DINGO K9-3 User Manual

Dingo K9-3 Operation & Maintenance Manual
26
Dingo K9-3 Operation & Maintenance Manual
27
9 1 K93-406 Pipe - Control Bank Dump
10 1 D95743 Pipe - Remote Bank To Control Bank 4B
11 1 D95744 Pipe - Wheel Control LH Lower 7AP Petrol
11 1 344-010-009 Pipe - Wheel Control LH Lower 6AD Diesel
12 1 D95745 Pipe - Wheel Control LH Upper 6AP Petrol
12 1 344-010-003 Pipe - Wheel Control LH Upper 7AD Diesel
13 1 D95746 Pipe - Wheel Control RH Lower 9AP Petrol
13 1 344-010-004 Pipe - Wheel Control RH Lower 8 ADDiesel
14 1 D95747 Pipe - Wheel Control RH Upper 8AP Petrol
14 1 344-010-005 Pipe - Wheel Control RH Upper 9AD Diesel
15 1 D95748 Pipe - Wheel Motor LH Lower 6BP Petrol
15 1 344-010-006 Pipe - Wheel Motor LH Lower 6BD Diesel
16 1 D95749 Pipe - Wheel Motor LH Upper 7BP Petrol
16 1 344-010-008 Pipe - Wheel Motor LH Upper 7BD Diesel
17 1 D95750 Pipe - Wheel Motor RH Lower 8BP Petrol
17 1 344-010-007 Pipe - Wheel Motor RH Lower 8BD Diesel
18 1 D95751 Pipe - Wheel Motor RH Upper 9BP Petrol
18 1 344-010-010 Pipe - Wheel Motor RH Upper 9BD Diesel
19 1 D95741 Pipe - Remote Bank 5B
20 1 330-003-004 Over Centre Valve
21 8 316-797-500 C3-1414 Fitting
22 1 Front Valve Bank Setup
23 1 D95703 Crowd Hose Short
24 1 D95705 Crowd Hose Long
25 2 D95707 Lift Arm Hose - Short
26 2 D95709 Lift Arm Hose - Long
27 1 D95711 Pressure Hose - Long (Petrol)
27 1 K93-723 Pressure Hose - Long (Diesel)
28 1 D95713 Pressure Hose - Short (Petrol)
28 1 K93-721 Pressure Hose - Short (Diesel)
29 1 D95715 Remote Hose - Short
30 1 D95717 Remote Hose - Long
31 2 D95718 Suction Hose (Petrol) 300mm
31 2 Suction Hose (Diesel) 650mm
32 2 317-565-555 C64-090909 Fitting
33 6 315-595-500 C59-0909 Fitting
34 1 318-132-000 Female Quick Release
35 1 318-131-000 Male Quick Release
36 1 310-400-002 Male Plug TM12
37 1 310-400-001 Female Cap TF12
38 4 300-000-003 Hose Clamp 29-31mm
39 2 111-211-065 Hex Bolt M6 x 65
40 2 121-121-000 Hex Nut Plain M6
41 4 111-311-060 Hex Bolt M8 x 60
42 9 121-131-000 Hex Nut Plain M8
43 4 131-131-000 Plain Washer M8
44 3 111-311-070 Hex Bolt M8 x 70
45 2 111-311-090 Hex Bolt M8 x 90
46 7 D95-722 Spacer 8mm
47 2 D95-723 Spacer 5mm
