Dingo K9-3 Operation & Maintenance Manual
28
Dingo K9-3 Operation & Maintenance Manual
29
Item Qty Part Number Description
10 1 515-000-003 Air Filter Assembly (Up to D014)
10 1 515-000-036 Air Filter Assembly ( D015 Onwards)
11 1 312-650-000 Plug Male 3/4” JIC Obsolete
12 1 316-306-500 Nipple Straight m/m CN2-0612
13 1 516-000-001 Fuel Tank Bracket Kit
14 1 516-000-021 Fuel Tank
15 1 516-000-003 Fuel Tank Cap
16 1 516-000-012 Fuel Filter
17 1 516-000-013 1/4” Fuel Line $$/Meter Kohler
1 516-000-013 1/4” Fuel Line $$/Meter Robin
18 1 D95-502 Top Fuel Tank Bracket
19 1 100-000-063 Hose Clamp 57mm
20 1 100-000-064 Hose Clamp 70mm
21 1 D95-350 Air Cleaner Bracket
22 2 D95-505 Fuel Tank Top Bracket Spacer
23 1 511-000-027 Kohler Mufer
1 D95357 Robin Mufer
24 1 515-000-012 Mufer Clamp
25 1 330-003-012 Centre Pump Washer
26 1 D95-360 Engine Mount Plate
27 1 D95-362 Kohler Mufer Extension
28 2 511-000-026 Kohler Exhaust Gasket
29 1 315-477-500 CP56-0814 Fitting
30 1 315-376-500 CP56-0612 Fitting
31 1 319-347-600 CP60-0812 Fitting
32 1 319-337-600 CP60-0612 Fitting
33 1 D95-353 Battery Bracket
34 1 D95-351 Heat Shield
35 1 410-000-013 Battery
36 1 410-000-056 Battery Lead Cover
37 2 410-000-016 Battery Lead 27”
38 2 410-000-014 Battery Small Lead 18”
39 1 516-000-025 Fuel Tap
40 1 516-000-013 1/4” Fuel Hose $$/Meter
41 2 516-000-016 Hose Clamp 1/4”
42 1 345-400-000 Oil Hose 1/2” Ortac $$/Meter
43 2 111-311-080 Hex Bolt M8 x 80
44 6 111-311-016 Hex Bolt M8 x 16
45 14 131-221-001 Plain Washer 5/16”
46 8 132-221-000 Spring Lock Washer M8
47 7 111-311-020 Hex Bolt M8 x 20
48 4 111-311-045 Hex Bolt M8 x 45
49 9 122-131-000 Nyloc Nut M8
50 2 120-132-000 M8 Speed Nut
51 4 111-311-025 Hex Bolt M8 x 25
52 4 111-322-025 Socket Head Cap Screw M8 x 25
53 1 516-000-010 Fuel Tank Bottom Packer
54 1 516-000-009 Fuel Tank Side Packer
55 1 516-000-008 Fuel Tank Top Packer
