Dingo K9-3 Operation & Maintenance Manual
31
Item Qty Part Number Description
1 1 K93-325 Radiator Shroud
2 1 519-000-002 Perkins Radiator
3 1 518-000-020 Radiator Cap
4 1 K93-345 Radiator Support Bracket
5 1 K93-318 Lower Radiator Hose
6 1 K93-319 Top Radiator Hose
7 1 K93-330 Fan Shroud
8 1 K93-812 Top Radiator Bracket (Shroud)
9 6 518-000-004 Mount Rubber
10 1 K93-811 Top Radiator Bracket (Engine)
11 1 519-000-015 Perkins Thermostat Gasket
12 1 K93 Perkins Thermostat
13 1 K93 Perkins Thermostat Housing
14 1 K93-825 Lower Radiator Mount
15 1 K93 Perkins Fan
16 1 519-000-011 K93 Perkins Fan Belt
17 1 K93-823 LH Front Engine Leg
18 1 K93-820 RH Front Engine Leg
19 2 K93-828 Angled Bolt Plate
20 2 K93-829 Bolt Plate
21 1 519-000-004 K93 Perkins Muffler
22 1 K93-304 Exhaust Heat Shield
23 8 M8 Flange Nut
24 8 519-000-017 M8x35mm Stud
25 2 Perkins Exhaust Flange
26 1 519-000-005 K93 Perkins Exhaust Pipe
27 1 519-000-002 403C-07 Perkins Engine
28 1 K94-826 Throttle Cable Link
29 1 519-000-016 K93 Perkins Oil Filter
30 1 K94-821 Throttle Cable Bracket
31 1 K93-335 Ignition Bracket
32 1 K93-317 K93 Perkins Air Cleaner Hose
33 3 100-000-063 57mm Hose Clamp
34 1 100-000-064
70mm Hose Clamp
35 1 K93-338 Air Cleaner Bracket
36 1 515-000-034 Inner Air Filter Element
37 1 515-000-033 Outer Air Filter Element
38 1 Pre Cleaner Hose
39 1 515-000-048 2 3/8” Hose Clamp
40 1 K94-336 Pre-Cleaner Pipe
41 1 Pre-Cleaner
42 1 330-005-019 Flex Drive Plate
43 1 330-005-020 Bell Housing Plate
44 1 K93-808 Pre-Cleaner Bracket
45 4 3/8” x 2” Stud
46 1 330-005-018 Spline Drive Coupling
