Forward-Facing Installation
38
WARNING:
• Always use Safe Stop with forward-facing child under 40 lbs.
• Do NOT use with rear-facing child.
• Do NOT use Safe Stop with any other installation configuration.
Safe Stop®
Safe Stop is a load-limiting device designed to absorb energy and
reduce impact to a smaller, forward-facing child. When not in use,
attach Safe Stop to the fabric label sewn onto the upper back of the
car seat cover.
Remove Safe Stop from the
storage label located on the
upper left back side of the car
seat.
Remove harness straps from
metal hook of harness
adjuster strap.
Thread both harness straps
onto metal hook of Safe Stop.
Connect left harness first then
right.
Thread bottom of Safe Stop
onto metal plate of harness
adjuster.
To Next Page
