Directechs Directed DB3 - Page 11

11
403.FORD6 3.24 2013 Ford Taurus (40-Bit)
©2022 VOXX•DEI LLC. All rights reserved.
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H2/9 Violet/Brown
(-) Trunk Hatch Release/Power Liftgate Output [1]
Trunk Release Switch, black 6 pin plug, pin 6
Not Applicable
- Brown/Yellow (except police)
H2/10 Yellow/Black (DATA) TX PATS Transceiver on ignition switch, black 4 pin plug, pin 3 Data Yellow/Orange
H2/11 Orange/Black (DATA) RX PATS Transceiver on ignition switch, black 4 pin plug, pin 4 Data Violet/Gray
H2/12 Blue/Red (-) Parking Light Output Must use a relay.
15A fuse to 12V
BCM under driver dash, gray 10 pin plug (E), pin 6
+ Yellow/Blue
Input 10-pin black connector (H3)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H3/1 Green No Connection No Connection
H3/2 Blue No Connection No Connection
H3/3 Red/White No Connection No Connection
H3/4 White/Violet No Connection No Connection
H3/5 Violet/Black No Connection No Connection
H3/6 White/Black (-) Hood Switch Input
H3/7 Pink/White No Connection No Connection
H3/8 Violet No Connection No Connection
H3/9 Pink No Connection No Connection
H3/10 Blue/White No Connection No Connection
D2D 4-pin white connector (H4)
Module
Conn./Pin Color Description
H4/1 Blue (Data) TX
H4/2 Black (-) Ground
H4/3 Green (Data) RX
H4/4 Red (+) 12 Volt
RF 2-pin white connector (H5)
Module
Conn./Pin Color Description
H5/1 N/A No Connection
H5/2 N/A No Connection
