Vehicle connections
The connection information listed below is specific to the 2013 Ford Taurus (40-Bit). Refer to “Pre-installation and application warnings” for a list of important notes.
Data 14-pin blue connector (H1)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H1/1 Light Green No Connection No Connection
H1/2 Violet/Yellow No Connection No Connection
H1/3 Tan/Black (DATA) MS CAN High OBD-Data Link Connector, black 16 pin plug, pin 3 Data Gray/Orange (MS CAN)
H1/4 Tan (DATA) MS CAN Low OBD-Data Link Connector, black 16 pin plug, pin 11 Data Violet/Orange (MS CAN)
H1/5 Orange/Green (DATA) HS CAN High OBD-Data Link Connector, black 16 pin plug, pin 6 Data White/Blue (HS CAN)
H1/6 Orange/Brown (DATA) HS CAN Low OBD-Data Link Connector, black 16 pin plug, pin 14 Data White (HS CAN)
H1/7 Brown Relay N.O. (+) 12 Volt Input Ignition Switch, black 7 pin plug, pin 4 + Yellow/Red (5A only)
H1/8 Yellow Relay COM (+) Ignition Output Ignition Switch, black 7 pin plug, pin 1 + White/Orange
H1/9 Orange/Yellow Relay N.C. No Connection No Connection
H1/10 Orange/Red Relay N.C. RAP Off Interrupt (vehicle side) BCM under driver dash, black 26 pin plug (C), pin 9 --or-- Driver Kick, door
harness
- N.C. Green/Violet
H1/11 Yellow/Red Relay COM RAP Off Interrupt (conn. side) BCM under driver dash, black 26 pin plug (C), pin 9 --or-- Driver Kick, door
harness
- N.C. Green/Violet
H1/12 Brown/Red Relay N.O. No Connection No Connection
H1/13 Red (+) 12 Volt Input Ignition Switch, black 7 pin plug, pin 4 + Yellow/Red (5A only)
H1/14 Black (-) Ground (chassis ground)
Output 12-pin red connector (H2)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H2/1 Black/White No Connection No Connection
H2/2 Green/Black
(-) Lock Output [1]
BCM under driver dash, black 26 pin plug (C), pin 6 - Blue/Green (test with
passenger switch on models
with memory)
H2/3 Green/White No Connection No Connection
H2/4 Red/Black
(-) Unlock Output [1]
BCM under driver dash, black 26 pin plug (C), pin 8 - Yellow/Violet (test with
passenger switch on models
with memory)
H2/5 Violet/White No Connection Any Fuel Injector, white 2 pin plug, pin 1 (3.5L/3.7L TIVCT) ac Green/Blue, Gray/Yellow,
Violet/Gray, Yellow/Orange,
Brown, or Green/White
H2/6 Gray (+) Starter Output Ignition Switch, black 7 pin plug, pin 7 + Blue/White
H2/7 Gray/Black (+) Accessory/Keysense Output Ignition Switch, black 7 pin plug, pin 6
Accessory required and Keysense ONLY required if OEM alarm equipped.
Must use a diode.
Ignition Switch, black 7 pin plug, pin 5
+
+
Violet/Green
Blue/Gray
H2/8 Violet/Green No Connection No Connection
To Next Page
