1133
©
2004 Directed Electronics, Inc.
its memory and will continue to chirp four or five times each time
the system is disarmed, until the next time the ignition is turned on.
A zone is represented by the number of LED flashes used by the
system to identify a particular type of input. Standard input assign-
ments are listed in the following table, along with spaces to write
in any optional sensors or switches that you have had installed.
ZZOONNEE
(Number of
DDEEAALLEERR--IINNSSTTAALLLLEEDD
LED Flashes)
DDEESSCCRRIIPPTTIIOONN OOPPTTIIOONNSS
11
Instant trigger for optional sensor,
hood or trunk pins
22
A heavier impact detected by
the on-board impact sensor
33
Door switch trigger
55
Ignition trigger
NNOOTTEE::
The LED does not report when the warn-away response has been
activated; it only reports triggered sequences.
TTaabbllee ooff ZZoonneess
