Directed 4113, 1-button series - Door Lock 3-pin Connector Wiring; Heavy Gauge Relay (H2) 6-pin Connector Wiring; Satellite Harness 4-pin Connector Wiring; Remote Start Harness (H3) 5-pin Connector Wiring

6
© 2012 Directed. All rights reserved.
Door Lock - 3 pin connector
1
LIGHT BLUE (-) UNLOCK
2
EMPTY NOT USED
3
GREEN (-) LOCK
Heavy Gauge Relay (H2), 6-pin connector
H2/1
PINK OUTPUT TO PRIMARY IGNITION CIRCUIT
H2/2
PURPLE OUTPUT TO STARTER CIRCUIT
H2/3
ORANGE OUTPUT TO ACCESSORY CIRCUIT
H2/4
RED (+) 30A HIGH CURRENT 12V INPUT
H2/5
PINK/WHITE OUTPUT TO SECOND IGNITION/ACCESSORY CIRCUIT
H2/6
RED (+) 30A HIGH CURRENT 12V INPUT
Satellite harness - 4-pin connector
1
BLUE (-) 200mA STATUS OUTPUT
2
ORANGE (-) 200mA ACCESSORY OUTPUT
3
PURPLE (-) 200mA STARTER OUTPUT
4
PINK (-) 200mA IGNITION OUTPUT
Remote Start harness (H3) 5-pin connector
H3/1 BLACK/WHITE (-) NEUTRAL SAFETY SWITCH INPUT
H3/2 VIOLET/WHITE TACHOMETER INPUT WIRE
H3/3 BROWN (+) BRAKE SHUTDOWN INPUT WIRE
H3/4 GRAY (-) HOOD PIN SWITCH SHUTDOWN WIRE
H3/5 BLUE/WHITE (-) 200 mA 2ND STATUS/REAR DEFOGGER
