Distech Controls EC-BOS-9 Quick Start Guide

2
7
LED
COM 1
A-RS485-B
COM 2
STAT BEAT
SEC PRI

   
 
1 RS485-A (COM1)
2 RS485-B (COM2)
3 STAT (Green)
4 BEAT (Yellow)
5 Ethernet (LAN2)
6 Ethernet (LAN1)
7 SHUT DOWN (Green, Behind Door)
6
Ground and Power
50/60Hz

Ground

Power
AC and
transformer
DC
1 Ground
2 Power
2.1 AC and transformer
2.2 DC
2.3 AC adapter
8
Ports and Switches
SHUT DOWN
DEBUG
COM 1 COM 2
STAT BEAT SEC PRI



1 SHUT DOWN button
2 SHUT DOWN “Job in progress” LED (Green)
3 DEBUG USB-C
i
Option (1)
2.44 (62)
0.34 in.
(8.6 mm)
0.165 in.
Dia.
(4.2 mm)
2.11 (53.5)
6.71 in. (170.5 mm)
3.31 in.
(84 mm)
3.31 in.
(84 mm)
4.33 in.
(110 mm)
6.38 in. (162 mm)
7.05 in. (179 mm)

Controller

Module
1 Controller
2 Module
i
Option (2)
2.13 in.
(54 mm)
2.13 in.
(54 mm)
6.71 in.
(170.5 mm)
3
