Distech Controls ECL-PTU-207 User Manual

11ECL-PTU-207 Preloaded Applications
CoolValveType (ConstantEnum7)
This variable is used to configure the Cooling or Change-Over Valve.
ID Enumeration Default Value
Constant Enum 7
0 = Unused: The valve is not used.
1 = 0-10V:: Only AO9 is used to control the valve.
2 = Thermal: DO5 is used to control the thermal valve and
AO9 to control the analog valve.
3 = On-Off: DO5 is used to control the digital valve and AO9 to
control the analog valve.
4 = Floating: DO5 and DO6 (DO5 = Open, DO6 = Close) are
used to control the Floating valve and AO9 to control the
analog valve.
Thermal
See IO assignement section for more details.
HeatValveType (ConstantEnum8)
This variable is used to configure the Heating Valve.
ID Enumeration Default Value
Constant Enum 8
0 = Unused: The valve is not used.
1 = 0-10V: Only AO10 is used to control the valve.
2 = Thermal: DO6 is used to control the thermal valve and
AO10 to control the analog valve.
3 = On-Off: DO6 is used to control the digital valve and AO10
to control the analog valve.
4 = Floating: DO5 and DO6 (DO5 = Open, DO6 = Close) are
used to control the Floating valve and AO10 to control the
analog valve.
Thermal
See IO assignement section for more details.
DamperCtrlType (ConstantEnum9)
This variable is used to configure the damper control type or disabled the damper control.
ID Enumeration Default Value
Constant Enum 9
0 = None: Damper Control is disabled.
1 = 0-10V : Damper used 0-10V signal type.
2 = 2-10V: Damper used 0-10V signal type
0-10V
See IO assignement section for more details.
