Ditch Witch 1820 - Transportation (Continued); Loading Machine Onto Trailer

1820 - TRANSPORTATION 31
LOADING
1820 - TRANSPORTATION 31
LOADING
LOADING
Load Machine
1. Start machine following instructions in OPERATION.
2. Push boom control (green) to lower boom as far as possible
without hitting ramps.
3. Engage axle lock (blue).
4. Push throttle (black) to 1/2 open.
EMERGENCY STOP: Release operator presence switch.
5. Move speed/direction control (orange) to forward or reverse
position.
To turn, move speed/direction control left or right.
6. Align trencher with ramps or trailer, boom first.
7. Guide trencher onto trailer.
8. When tie down position is reached, move speed/direction
control (orange) to neutral position.
9. Push boom control (green) to lower boom.
10. Disengage pump control.
11. Pull throttle to turtle.
12. Turn key to off position.
13. Close fuel shut-off valve on gasoline engine.
14. Tiedown trencher to trailer.
