Ditch Witch 1820 - Specifications (Continued); Gasoline Engine Specifications; Diesel Engine Specifications

82 1820 - SPECIFICATIONS
82 1820 - SPECIFICATIONS
** With 16” pivot option
POWER OPTIONS: U.S. METRIC
Engine (Honda GX610)
Fuel — Gasoline
Cooling medium — Air
Number of cylinders — 2
Displacement 37.5 in
3
614 cm
3
Bore 3.03 in 77 mm
Stroke 2.60 in 66 mm
Manufacturers net power rating (per
SAE J1349)
18 hp 13.4 kW
Rated speed 3600 rpm* 3600 rpm*
Maximum torque @ 2500 rpm 31.8 ft•lb 43.1 N•m
Max. tilt angle** All directions 20° 20°
Engine (Kubota D722-E)
Fuel — Diesel
Cooling medium — Water
Number of cylinders — 3
Displacement 43.88 in
3
719 cm
3
Bore 2.64 in 67 mm
Stroke 2.68 in 68 mm
Engine manufacturers gross power
rating @ 3600 rpm
18.8 hp 14.0 kW
Maximum governed speed as
installed (no load)*
3200 rpm* 3200 rpm*
Flywheel power @ 3000 rpm (full
load)
17.6 hp 13.1 kW
Fuel consumption @ 3000 rpm 1.0 gph 3.8 L/h
Max. tilt angle** All directions 20° 20°
*Product support may be void if engine is run above "Maximum governed speed
as installed (no load)."
** With 16” pivot option
POWER OPTIONS: U.S. METRIC
Engine (Honda GX610)
Fuel — Gasoline
Cooling medium — Air
Number of cylinders — 2
Displacement 37.5 in
3
614 cm
3
Bore 3.03 in 77 mm
Stroke 2.60 in 66 mm
Manufacturers net power rating (per
SAE J1349)
18 hp 13.4 kW
Rated speed 3600 rpm* 3600 rpm*
Maximum torque @ 2500 rpm 31.8 ft•lb 43.1 N•m
Max. tilt angle** All directions 20° 20°
Engine (Kubota D722-E)
Fuel — Diesel
Cooling medium — Water
Number of cylinders — 3
Displacement 43.88 in
3
719 cm
3
Bore 2.64 in 67 mm
Stroke 2.68 in 68 mm
Engine manufacturers gross power
rating @ 3600 rpm
18.8 hp 14.0 kW
Maximum governed speed as
installed (no load)*
3200 rpm* 3200 rpm*
Flywheel power @ 3000 rpm (full
load)
17.6 hp 13.1 kW
Fuel consumption @ 3000 rpm 1.0 gph 3.8 L/h
Max. tilt angle** All directions 20° 20°
*Product support may be void if engine is run above "Maximum governed speed
as installed (no load)."
