Ditch Witch C24x User Manual

Cx Series Operator’s Manual Specifications - 117
C30x
Operation US Metric
Vehicle speeds
Max transit forward 176fpm 53.6m/min
Max transit reverse 136fpm 41.5m/min
Digging chain speed
19K 366fpm 111.6m/min
35K 309fpm 94.2m/min
Spoils handling, single, open-end auger
Outer diameter 17” 432mm
Max operating weight 2100lb 953kg
Engine US Metric
Engine: Briggs & Stratton® Vanguard™ 31.0 big block, V-twin horizontal shaft
Fuel gasoline
Cooling medium air
Number of cylinders 2
Displacement
54.68in
3
896cm³
Bore 3.37” 86mm
Stroke 3.07” 78mm
Manufacturer’s net power rating @3600rpm (per SAE J1940) 31hp 23.1kW
Rated speed 3600rpm 3600rpm
Fuel consumption 2.49gph 9.4L/h
Max tilt angle* 20° 20°
* Exceeding these operational angles will cause engine damage. This DOES NOT IMPLY machine is stable to maximum angle of
safe engine operation.
Battery
310 CA, 12V, reserve capacity 30 min

Ditch Witch C24x Specifications

General

Engine Make	Kubota
Engine Type	Diesel
Transmission	Hydrostatic
Gross Power	24.8 hp
Max Digging Depth	5 ft
Width	48 in
Horsepower	24.8 hp
Max Trenching Depth	5 ft
