JT30 /JT30 All Terrain Operator’s Manual Controls - 32
Left Control Console
CMW
Most engine display functions are self-explanatory. For more information about functions, see the
manufacturer’s instructions at www.fwmurphy.com.
4. Engine coolant
temperature gauge
Displays engine coolant
temperature.
Normal coolant temperature is 160°-
212° F (71°-100° C).
5. Screen brightness soft
key command
Displays screen brightness
setting.
To access screen brightness menu,
press soft key. Select day or night
setting.
6. Menu key Press at any time to return to
main menu.
This key may be used for another
function. If so, a soft key command
will display.
7. Voltmeter display Shows system voltage. Normal voltage is 13-14V with engine
running.
8. Hour meter Displays number of hours
engine has been running.
9. Engine oil pressure
gauge
Displays engine oil pressure. Full load reading should be 60-80 psi
(4.1-5.5 bar).
10. Enter key Press to finalize a selection. This key may be used for another
function. If so, a soft key command
will display.
Item Description Notes
