1592017000 XLR 130-170 GB r2.0 23.03.2015 XL130 - XLR170 13/20
8. INSTALLATION AND MOUNTING
The temperature range allowed for correct operation is 0 - 60 °C. Avoid places subject to strong vibrations, corrosive gases, excessive dirt or
humidity. The same recommendations apply to probes. Let the air circulate by the cooling holes.
Thanks to the case, XLR130 and XLR170 models can be panel or wall mounted. See the following instructions for details.
A
B
C
D E
GF
FIG. 1
A
B
C
G
F
D
FIG. 2
87
230
M
A
X
3
7
210
130
120
M
A
X
2
8
H
I
FIG. 3
