1592017000 XLR 130-170 GB r2.0 23.03.2015 XL130 - XLR170 17/20
Serial output : TTL standard
Communication protocol: Modbus - RTU
Data storing: on the non-volatile memory (EEPROM).
Internal clock back-up: 24 hours
Kind of action: 1B; Pollution grade: normal; Software class: A.
Operating temperature: 0÷60 °C.
Storage temperature: -25÷60 °C.
Relative humidity: 20
÷85% (no condensing)
Measuring and regulation range: NTC probe: -40÷110°C (-58÷230°F)
Resolution: 0,1 °C or 1°C or 1 °F (selectable).
Accuracy (ambient temp. 25°C): ±0,5 °C ±1 digit
15. CONNECTIONS
15.1 XLR130
15.1.1 FREE VOLTAGE CONTACTS
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34
Light
16A
250V~
20A 250V
16FLA(96LRA)
20A 250V
16FLA(96LRA)
8A
250V~
N
Alarm
NC
35 36
RS 485
optional
Comp
15.1.2 DIRECT LOAD CONNECTIONS
15.2 XLR170
15.2.1 FREE VOLTAGE CONTACTS
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
16 17 18 19 20 2 1 22 23 24 25 26 27 28 29 30 31 32 33 34
Light
16A
250V~
16A
250V~
8A
250V~
20A 250V
16FLA(96LRA)
20A 250V
16FLA(96LRA)
8A
250V
~
N
Comp
Line
Def.
NC
Alarm
NC
Fan
35 36
RS 485
optional
15.2.2 DIRECT LOAD CONNECTIONS
