1592026020 XW60K GB R2.1 22.06.2012.doc XW60K 6/6
Label
Name Range Default
Level
P2P Evaporator probe presence n=not present; Y=pres. Y Pr1
oE Evaporator probe calibration
[-12 to 12°C]
[-21 to 21°F]
0.0 Pr2
P3P
Third probe presence (1st cond.
probe)
n=not present; Y=pres. n Pr2
o3 Third probe calibration
[-12 to 12°C]
[-21 to 21°F]
0 Pr2
P4P
Fourth probe presence (2nd
cond. probe)
n=not present; Y=pres. n Pr2
o4 Fourth probe calibration
[-12 to 12°C]
[-21 to 21°F]
0 Pr2
odS
Outputs activation delay at start
up
0 to 255 min 0 Pr2
AC Anti-short cycle delay 0 to 30 min 1 Pr1
Ac1 Second compressor delay 0 to 255 sec 5 Pr2
rtr P1-P2 percentage for regulation 0 to 100 (100=P1 , 0=P2) 100 Pr2
CCt
Compressor ON time during fast
freezing
0.0 to 23h50min, res. 10 min 0.0 Pr2
CCS
Set point for continuous cycle
[-55.0 to 150.0°C]
[-67 to 302°F]
-5 Pr2
Con
Compressor ON time with faulty
probe
0 to 255 min 15 Pr2
CoF
Compressor OFF time with faulty
probe
0 to 255 min 30 Pr2
DISPLAY
CF Temperature measurement unit °C; °F °C Pr2
rES Resolution (integer/decimal point)
in; dE dE Pr1
rEd Remote display P1; dtr P1 Pr2
dLy Display temperature delay 0.0 to 20min00sec, res. 10 sec 0 Pr2
dtr P1-P2 percentage for disply 1; 100 50 Pr2
DEFROST
tdF Defrost type EL; in EL Pr1
dFP
Probe selection for defrost
termination
nP; P1; P2; P3; P4 P2 Pr2
dtE Defrost termination temperature
[-50.0 to 150°C]
[-58 to 302°F]
8.0 Pr1
idF Interval between defrost cycles 1 to 120 h 6 Pr1
MdF
(Maximum) length for 1° defrost 0 to 255 min 30 Pr1
dSd Start defrost delay 0 to 99 min 0 Pr2
dFd Displaying during defrost rt; it; SEt; dEF; dEG it Pr2
dAd MAX display delay after defrost 0 to 255 min 30 Pr2
Fdt Draining time 0 to 60 min 0 Pr2
dPo First defrost after start up n; Y n Pr2
dAF Defrost delay after fast freezing 0.0 to 23h50min, res. 10 min 0.0 Pr2
FANS
FnC Fans operating mode C-n; C-y; O-n; O-y o-n Pr1
Fnd Fans delay after defrost 0 to 255 min 10 Pr1
FCt
Differential of temperature for
forced activation of fans
[0 to 50°C]
[0 to 90°F]
10 Pr2
FSt Fans stop temperature
[-55.0 to 50°C]
[-67 to 302°F]
2 Pr1
Fon Fan on time with compressor off 0 to 15 min 0 Pr2
FoF Fan off time with compressor off 0 to 15 min 0 Pr2
FAP
Probe selection for fan
management
nP; P1; P2; P3; P4 P2 Pr2
AUXILIARY THERMOSTAT
ACH
Kind of action for auxiliary relay CL; Ht CL Pr2
SAA
Set Point for auxiliary relay
[-55.0 to 150°C]
[-67 to 302°F]
0.0 Pr2
SHy
Differential for auxiliary relay
[0.1 to 25.5°C]
[1 to 45°F]
2.0 Pr2
ArP Probe selection for auxiliary relay nP; P1; P2; P3 nP Pr2
Sdd Aux.output working during defrost
n; Y n Pr2
ALARMS
ALP
Probe setting for temperature
alarm
P1; P2; P3; P4 P1 Pr2
ALC
Temperature alarms configuration
rE; Ab rE Pr2
ALU
MAXIMUM temperature alarm
[-55.0 to 150.0°C]
[-67 to 302°F]
10.0 Pr1
ALL minimum temperature alarm
[-55.0 to 150.0°C]
[-67 to 302°F]
10.0 Pr1
AFH
Temperature alarm and fan
differential
[0.1 to 25.5°C]
[1 to 45°F]
2.0 Pr2
ALd Temperature alarm delay 0 to 255 min 15 Pr2
dAo
Delay of temperature alarm at
start up
0.0 to 23h50min, res. 10 min 1.3 Pr2
AP2
Probe for temperat. alarm of
condenser
nP; P1; P2; P3; P4 P4 Pr2
AL2
Condenser for low temperat.
alarm
[-55.0 to 150.0°C]
[-67 to 302°F]
-40 Pr2
AU2
Condenser for high temperat.
alarm
[-55.0 to 150.0°C]
[-67 to 302°F]
110 Pr2
AH2
Differential for condenser
temperature alarm recovery
[0.1 to 25.5°C]
[1 to 45°F]
5 Pr2
Ad2
Condenser temperature alarm
delay
0 to 254 min , 255=nU 15 Pr2
dA2
Delay of cond. temper. alarm at
start up
0.0 to 23h50min, res. 10 min 1.3 Pr2
bLL
Compressor off because of
condenser low temperature alarm
n(0); Y(1) n Pr2
Label
Name Range Default
Level
AC2
Compr. off for condenser high
temperature alarm
n(0); Y(1) n Pr2
AUXILIARY OUTPUT
tbA Alarm relay disabling n=no; Y=yes Y Pr2
oA3 Fourth relay configuration
ALr = alarm; dEF = do not select it; Lig
=Light; AUS =AUX; onF=always on; Fan=
do not select it; db = do not select it; dF2 =
do not select it
Lig Pr2
AoP Alarm relay polarity (oA3=ALr) oP; CL CL Pr2
DIGITAL INPUT
i1P Digital input polarity oP=opening;CL=closing CL Pr1
i1F Digital input configuration EAL; bAL; PAL; dor; dEF; Htr; AUS dor Pr1
did Digital input alarm delay 0 to 255 min 15 Pr1
nPS
Number of activation of pressure
switch
0 to 15 15 Pr2
odC
Compress and fan status when
open door
no; FAn; CPr; F_C F-C Pr2
rrd
Regulation restart with door open
alarm
n; Y Y Pr2
LES
Light off during energy saving
status
n; Y Y Pr2
HES
Differential for Energy Saving
[-30 to 30°C]
[-54 to 54°F]
0 Pr2
RTC
Hur*
Current hour read only - rtc
Min*
Current minute read only - rtc
dAY*
Current day read only - rtc
dYM*
Day of the month read only - rtc
Mon
Month read only - rtc
YAr Year read only - rtc
Hd1*
First weekly holiday Sun to SAt; nu nu rtc
Hd2*
Second weekly holiday Sun to SAt; nu nu rtc
ILE*
Energy Saving cycle start during
workdays
0.0 to 23h50min 0 rtc
dLE*
Energy Saving cycle length during
workdays
0.0 to 24h00min 0 rtc
ISE*
Energy Saving cycle start on
holidays
0.0 to 23h50min 0 rtc
dSE*
Energy Saving cycle length on
holidays
0.0 to 24h00min 0 rtc
Ld1*
1
st
workdays defrost start 0.0 to 23h50min; nu 6.0 rtc
Ld2*
2
nd
workdays defrost start 0.0 to 23h50min; nu 13.0 rtc
Ld3*
3
rd
workdays defrost start 0.0 to 23h50min; nu 21.0 rtc
Ld4*
4
th
workdays defrost start 0.0 to 23h50min; nu 0.0 rtc
Ld5*
5
th
workdays defrost start 0.0 to 23h50min; nu 0.0 rtc
Ld6*
6
th
workdays defrost start 0.0 to 23h50min; nu 0.0 rtc
Sd1*
1
st
holiday defrost start 0.0 to 23h50min; nu 6.0 rtc
Sd2*
2
nd
holiday defrost start 0.0 to 23h50min; nu 13.0 rtc
Sd3*
3
rd
holiday defrost start 0.0 to 23h50min; nu 21.0 rtc
Sd4*
4
th
holiday defrost start 0.0 to 23h50min; nu 0.0 rtc
Sd5*
5
th
holiday defrost start 0.0 to 23h50min; nu 0.0 rtc
Sd6*
6
th
holiday defrost start 0.0 to 23h50min; nu 0.0 rtc
OTHER
Adr Serrial address 1 to 247 1 Pr1
PbC Kind of probe PtC; ntC ntC Pr2
onF on/off key enabling nu, oFF; ES oFF Pr2
dP1 Room probe display read only - Pr1
dP2 Evaporator probe display read only - Pr1
dP3 Third probe display read only - Pr1
dP4 Fourth probe display read only - Pr1
rSE Current set point read only Pr1
rEL Software release read only - Pr2
Ptb Map code read only - Pr2
* Only for model with real time clock
