Dixie Narco DNCB 276E - E-Model Shimming Guide

Set-up subject to change without notice. For packages not listed contact Dixie-Narco Factory Service at (800) 688-9090. Page 21 of 72
E-MODEL SHIMMING
Package Model Loading
Depth
Cam(s)
Setting
Wide Column Shims Cam(s)
Setting
Narrow Column Shims Rear
Spacer
12 oz. Can
2.60" x 4.84"
501E
600E
276E
3 grey/red
(#2)
Shim, 3/16 Flat (801,809,72x.x1)
2 per side
brown
(#1)
Shim, Can Stop (609,070,14x.x3)
1 per right side
Assy, Bottle Rod
(609,070,30x.x3)
1 per rotor - "B" hole
#13
20 oz. PET Pepsi Quick Slam
2.89" x 8.60"
501E
600E
276E
2 grey/red
(#3)
Shim, 3/32 Flat (801,809,81x.x1)
2 per side
brown
(#5)
Shim, Bottle (609,070,15x.x3)
1 per right side
#21
20 oz. PET Coke Contour
2.86" x 9.03"
501E
600E
276E
2 grey/red
(#3)
Shim, 3/32 Flat (801,809,81x.x1)
1 per side
brown
(#5)
Shim, Bottle (609,070,15x.x3)
1 per right side
#24
20 oz. PET All Sport
2.88" x 8.18"
501E
600E
276E
2 grey/red
(#3)
Shim, 3/32 Flat (801,809,81x.x1)
1 per side
brown
(#5)
Shim, Bottle (609,070,15x.x3)
1 per right side
#18
20 oz. PET Powerade
2.86" x 7.74"
501E
600E
276E
2 grey/red
(#3)
Shim, 3/32 Flat (801,809,81x.x1)
2 per side
Extension Oscillator Paddle
w/bottle stop (324,010,21x.x3)
1 screw, #8-18x3/4
(900,302,02x.x1)
brown
(#5)
Shim, Bottle (609,070,15x.x3)
1 per right side
Can/Bottle Chute Assy.
w/extensions (609,072,50x.x3
wide or 615,070,60x.x3 narrow)
1 per vender
#15
20 oz. PET Straight Wall
2.89" x 8.0"
501E
600E
276E
2 grey/red
(#3)
Shim, 3/32 Flat (801,809,81x.x1)
1 per side
brown
(#5)
Shim, Bottle (609,070,15x.x3)
1 per right side
#18
16 oz. Glass Non Returnable
2.95" x 7.2"
501E
600E
276E
2 grey/red
(#1)
Shim, 3/32 Flat (801,809,81x.x1)
1 per side
brown
(#5)
Shim, Bottle (609,070,15x.x3)
1 per right side
#12
20 oz. PET Mt. Shasta
2.89" x 8.0"
501E
600E
276E
2 (#3) Shim, 3/32 Flat (801,809,81x.x1)
1 per side
(#5) Shim, Bottle (609,070,15x.x3)
1 per right side
#17
20 oz. PET Aqua Fina
2.86" x 8.63"
501E
600E
276E
2 grey/red
(#3)
Shim, 3/32 Flat (801,809,81x.x1)
2 per side
brown
(#5)
Shim, Bottle (609,070,15x.x3)
1 per right side
Assy, Bottle Divider – 1 per
column
(609,072,30x.x3) - 501E/276E
(609,072,40x.x3) - 600E
#21
20 oz. PET Sprite Bottle
2.89" x 9.06"
501E
600E
276E
2 (#3) Shim, 3/32 Flat (801,809,81x.x1)
1 per side
(#5) Shim, Bottle (609,070,15x.x3)
1 per right side
#22
