INSTALLING A COIN CHANGER
Hang the coin changer on its mounting plate and secure it by tightening the three securing screws. Plug
the coin changer into the appropriate changer socket.
CAUTION: ON SIID VENDERS THE COIN CHANGER MUST BE PLUGGED IN WITH
THE POWER REMOVED FROM THE DOOR OR THE COIN CHANGER MAY
NOT POWER ON PROPERLY. IF A BILL ACCEPTOR IS BEING USED, THE
BILL ACCEPTOR MUST BE INTERFACED PROPERLY TO THE COIN
CHANGER OR CONTROL BOARD.
After restoring power, manually load the coin changer coin tubes with at least ten coins each. In SIID
venders, follow the program instructions and program each selection for its own vend price. A price of
$0.00 is free vend. After the pricing is set, return the vender to its operate mode either by closing the
door or pulling the door closed switch out. In single price venders, follow the instructions for the coin
changer provided by the manufacturer. "Prime" the coin changer by making a correct change
transaction.
BILL ACCEPTORS
If a bill acceptor is not factory installed, the proper interface harness must be ordered. Also, refer to the
instructions provided by the coin changer and bill acceptor manufacturers.
BILL ACCEPTOR INTERFACE HARNESSES - SINGLE PRICE
See instructions provided by the bill acceptor manufacturer.
T-Adapter (for use with hi level Note Acceptors) – 805,501,14x.x1
BILL ACCEPTOR INTERFACE HARNESSES - SIID
Acceptor Pepsi-Cola & Other
Venders
Coca-Cola Venders
Ardac USA 804,909,72x.x1 (lo level) not applicable
Mars VFM-1, VFM-3, & VN2000 Series *804,912,59x.x1 (lo level) not applicable
Maka NB-10L-200 804,909,76x.x1 (hi level) not applicable
Coinco/Rowe CBA-2 $1 Only *804,909,75x.x1 (hi level) not applicable
Row CBA-2 $1 & $5 (UBA-2) *804,909,75x.x1 (hi level) not applicable
Mars VFM-1 & VFM-3 804,909,74x.x1 (hi level) not applicable
Coinco BA30 *804,909,79x.x1 (hi level) not applicable
Coinco BA30 (Mdb) 804,912,61x.x1 (Mdb) 804,912,61x.x1 (Mdb)
Mars VN2000 Series (Mdb) *multidrop bus *multidrop bus
*also requires parts from acceptor manufacturer.
Note: Bill acceptors will be inhibited anytime the door interlock switch is in the center
position (service mode enable), even if service mode time-out has occurred,
restoring the vender to normal operation.
OTHER ACCESSORIES
SIID venders are capable of interfacing to Debit Card and Data Recording systems. Presently Dixie-
Narco has tested only a few such accessories. If such accessories are to be used, check with either
Dixie-Narco or the accessory manufacturer about physical and electrical compatibility before attempting
to interface such accessories to the SIID vender.
