DJI FlyCart 30 Winch System User Guide
Cargo Mounting Methods
Select how to mount the cargo according to the cargo volume and method of
transportation.
• The cables that come with the package are to be used only on the winch system
itself, DO NOT use them to secure the cargo.
• DO NOT let the cable make contact with sharp objects, as to avoid damage.
Replace the cable if it is damaged.
• The minimum weight of cargo for the winch system is 5 kg. The maximum weight
is 30 kg when in dual battery mode and 40 kg in single battery mode.
• The extension cable can be used when there is a large volume of cargo that
cannot be placed within the landing gear or if the density of the cargo (e.g. a steel
block) is so great that it may damage the aircraft.
• It is recommended to install the counterweight to avoid having the cable get stuck
or reel up in reverse. Attach the counterweight to the hook of the winch system by
tightening the screws.
Mounting a Small Cargo Volume
When there is a small volume of cargo and it can be placed within the landing gear,
users can secure the cargo with ropes and hang it by the hook of the winch system.
• If the cargo only needs to be delivered once, leave a rope length between 20 cm and
40 cm and secure it with a knot. Hang the cargo on the hook using the rope loop, as
shown in Figure 1. Make sure the hook can move freely within the rope loop.
• Ifthecargoneedstobedeliveredforseveraltimes,usearunwaytypecarabiner(≥8mm
diameter)orasteelring(≥5mmdiameter)andfixtotheendoftherope,asshownin
Figures 2 and 3.
• DO NOT tie a knot on the hook directly. Otherwise, the cargo cannot be released
automatically.
• Theropespreparedbyuserarerequiredtobe≥6mmindiameter.Makesurethe
ropes are in good condition and durable.
Figure 1 Figure 2 Figure 3
