DJI Inspire 3 Maintenance Manual
8
©
2023 DJI All Rights Reserved.
Inspection and Maintenance
Routine inspection before operations or regular maintenance can greatly improve the reliability
of the aircraft, reduce potential safety hazards, and extend the service life of the aircraft. Make
sure to check the following items carefully.
Propulsion System
Motor Rotation
• Rotate the propeller motors to check if the propellers are jammed or make any abnormal
sounds and whether the rotor and stator of the motors scratch the motor base.
• DO NOT y the aircraft if the propellers are jammed or make any abnormal sounds. If there
are any abnormalities, make sure to return the aircraft to the factory for repair.
Connection between Motor and Frame Arm
• Rotate the motor base around the central line of the carbon tube to check if the motor and
carbon tube connection is rmly secure.
• The six xing screws are securely tightened.
• The ball hinge tightening screws are securely tightened.
• If any screws are loose, return the aircraft to the factory for repair.

dji INSPIRE 3 Specifications

General

Camera Sensor	Full-Frame CMOS
Obstacle Sensing	Omnidirectional
Max Ascent Speed	8 m/s
Max Descent Speed	8 m/s
Internal Storage	1 TB SSD
Gimbal	3-axis (tilt, roll, pan)
Camera	Zenmuse X9-8K Air
Effective Pixels	24 MP
Gimbal Stabilization	±0.01°
Transmission System	DJI O3 Pro
Live View Quality	1080p/60fps
Remote Controller	DJI RC Plus
Remote Controller Charging Port	USB-C
Flight Time	28 minutes
Transmission Range	15 km
Max Speed	94 km/h
Operating Temperature	-20°C to 40°C
GNSS	GPS + Galileo + BeiDou
Operating Frequency	2.4000-2.4835 GHz; 5.725-5.850 GHz
Transmitter Power (EIRP)	2.4 GHz: <33 dBm; 5.8 GHz: <33 dBm
Hovering Accuracy Range	Vertical: ±0.1 m; Horizontal: ±0.3 m
ISO Range	Video: 100-25600
Shutter Speed	1/8000s to 2s
Supported File Formats	JPEG, DNG, MP4, MOV
Latency	90 ms
Remote Controller Operating Frequency	2.4000-2.4835 GHz; 5.725-5.850 GHz
Supported SD Cards	microSD
Video Resolution	8K
