MATRICE 600 PRO User Manual
[1] System Status
Ready to Go (GPS)
: Indicates the current aircraft system status and GPS signal strength.
[2] Battery Level Indicator
: Describes the battery level of the aircraft according to its immediate status. The colored
zones represent the various stages of battery level. When the battery level drops to a certain
stage, the system will prompt the user to take the appropriate action.
[3] Flight Mode
: The text next to this icon indicates the current ight mode.
Tap this icon to congure the Main Controller Settings, to change the ight limits and set the gain
values.
[4] GPS Signal Strength
: Shows the current GPS signal strength. White bars indicate adequate GPS strength.
[5] Remote Controller Signal
: Shows the signal strength of the remote controller.
[6] HD Video Link Signal Strength
: Shows the signal strength of the HD video downlink between the aircraft and the remote
controller.
[7] Battery Level
61%
: Shows the current battery level.
Tap this icon to view the battery information menu where you can set the battery warning
thresholds and view the battery log.
[8] General Settings
: Tap this icon to view General Settings where you can set the ight parameters, and enable
the Flight Route display.
[9] Camera Operation Bar
This bar will be displayed when using a Zenmuse Z30, Z3, X3, X5 series, XT or XT 2 gimbal and
camera.
Photo / Video Button
: Tap to switch between photo and video recording modes.
Shoot / Record Button
/ : Tap to start shooting photos or recording video.
Camera Settings
: Tap this icon to set the ISO, Shutter Speed and Exposure Value of the camera.
Playback
: Tap this icon to play back photos and videos after they are captured.
