dji Matrice 600 Pro

10
©
2017 DJI All Rights Reserved.
6. For the GPS in the remote controller to function properly and the Home Point to be accurate, ensure the
DJI logo is facing the sky and keep the remote controller away from any metal objects.
7. Linking is required if you wish to replace your remote controller or receiver or add a new remote controller.
Refer to the User Manual for details.
8. Make Sure that you rst switch off the aircraft (after it is safe to do so), then switch off the remote controller.
Otherwise it may cause the lost of control of the aircraft.
Center Frame
To avoid component malfunction, serious injury, and property damage, observe the following rules:
1.
DO NOT short out the reserved ports on the center frame.
2.
There are two DC18V power ports and one LIPO-6S power port reserved on the center frame. The
DC18V power ports have an output voltage of 18 V and a maximum output current of 3 A. The
LIPO-6S power port has the same output voltage as the Intelligent Flight Battery and a maximum
output current of 10 A. Use the power ports in strict accordance with their specications.
3.
DO NOT damage the cables when mounting or removing the upper or lower plate of the center frame.
Frame Arms
To avoid component malfunction, serious injury, and property damage, observe the following rules:
1.
The external antennas of the Lightbridge 2 Air System are mounted to the M3 and M6 frame arms
upon delivery. DO NOT move the antennas.
Retractable Modules
To avoid component malfunction, serious injury, and property damage, observe the following rules:
1.
DO NOT interchange the cabling of the left and right retractable modules, or else the landing gear
will not function normally.
Landing Gears
To avoid component malfunction, serious injury, and property damage, observe the following rules:
1.
Mind your ngers when mounting the springs to the landing gears.
2.
Ensure the landing gears are lowered before landing.
