Appendix
Specifications
General
Built-In Functions
(1) Three Modes of Autopilot
(2) Enhanced Fail Safe
(3)Low Voltage Protection
(4)S-Bus Receiver Support
(5)PPM Receiver Support
(6)2-axle Gimbal Support
Peripheral
Supported Multi-rotor
Quad-rotor I4, X4;
Hexa-rotor I 6, X6, IY6, Y6.
Octo- rotor I8, V8, X8
Supported ESC output
400Hz refresh frequency.
Recommended Transmitter
PCM or 2.4GHz with a minimum 4 channels.
Assistant Software System Requirement
Windows XP SP3; Windows 7; Windows 8
Electrical & Mechanical
Working Voltage Range
MC: 4.8V ~ 5.5 V
PMU Input: 7.4V ~ 26.0 V (recommend 2S ~ 6S LiPo)
Output(V-SEN port red wire): 3A@5V
Output(V-SEN port red wire)burst current:7.5A
Power Consumption
MAX: 1.5W(0.3A@5V)
Normal: 0.6W(0.12A@5V)
Operating Temperature
-10°C ~ 50°C (14F ~122F)
Weight
MC: 27g
GPS/Compass: 27g
PMU: 28g
LED: 13g
Dimensions
MC: 45.5mm × 32.5mm × 18.5mm
GPS/Compass: 46mm (diameter) x 10mm
PMU39.5mm × 27.5mm × 10.0mm
LED25mm × 25mm × 7.0mm
Flight Performance (can be effected by mechanical performance and payloads)
Hovering Accuracy (GPS Mode)
Vertical: ±± 0.8m
Horizontal: ±±2.5m
Max Yaw Angular Velocity
200°/s
Max Tilt Angle
3
Max Ascent / Descent Speed
±Ascent : 6m/s, Descent: 4.5 m/s
