dji Naza-M V2 User Manual

©2013 DJI Innovations. All Rights Reserved.
V1 Specification
General
Built-In Functions
 Three Modes of Autopilot
 Enhanced Fail Safe
 Low Voltage Protection
 S-Bus Receiver Support
 PPM Receiver Support
 2-axle Gimbal Support
Peripheral
Supported Multi-rotor
 Quad-rotor I4, X4;
 Hexa-rotor I 6, X6, IY6, Y6.
 Octo-rotor I8, V8, X8 (Upgrade the MC Firmware to
V3.10 or above)
Supported ESC output
400Hz refresh frequency.
Recommended Transmitter
PCM or 2.4GHz with a minimum 4 channels.
Assistant Software System Requirement
Windows XP SP3; Windows 7
Electrical & Mechanical
Working Voltage Range
 MC: 4.8V ~ 5.5 V
 VU Input: 7.2V ~ 26.0 V (recommend 2S ~ 6S LiPo)
Output(V-SEN port red wire): 3A@5V
Output(V-SEN port red wire)burst current:7.5A
Power Consumption
 MAX: 1.5W(0.3A@5V)
 Normal: 0.6W(0.12A@5V)
Operating Temperature
-10°C ~ 50°C(14F ~122F)
Weight
 MC: 25g
 GPS: 21.3g
 VU: 20g
Dimensions
 MC: 45.5mm × 31.5mm × 18.5mm
 GPS & Compass: 46mm (diameter) x 9mm
 VU: 32.2mm × 21.1mm × 7.7mm
Flight Performance (can be effected by mechanical performance and payloads)
Hovering Accuracy (GPS Mode)
 Vertical: ±± 0.8m
 Horizontal: ±± 2.5m
Max Yaw Angular Velocity
200°/s
Max Tilt Angle
45°
Max Ascent / Descent Speed
±6m/s

dji Naza-M V2 Specifications

General

Working Voltage	4.8V - 5.5V
Operating Temperature	-10°C to 50°C
Firmware Update	Supported
Max Supported Motors	8
Communication Interface	USB
Firmware Upgradeable	Yes
Built-in Functions	Intelligent Orientation Control (IOC)
Assistant Software	DJI NAZA Assistant Software
Supported ESC Output	400Hz
Recommended Transmitter	PCM or 2.4GHz with minimum 4 channels
Power Consumption (Typical)	0.4W
GPS Compatibility	Yes
Flight Modes	Manual Mode, Atti. Mode, GPS Atti. Mode
