dji OSMO MOBILE 6 User Manual

18
©
2022 DJI All Rights Reserved.
Specifications
General
Gimbal Dimensions
Unfolded: 276×111.5×99 mm (L×W×H)
Folded: 189×84.5×44 mm (L×W×H)
Weight
Gimbal: Approx. 309 g
Magnetic Phone Clamp: Approx. 31 g
Max Length of Built-in Extension Rod 215 mm
Compatible Phone Weight 170-290 g
Compatible Phone Thickness 6.9-10 mm
Compatible Phone Width 67-84 mm
Battery
Type Li-Po 2S
Chemical System LiCoO2
Capacity 1000 mAh
Energy 7.74 Wh
Voltage 6-8.8 V
Charging Temperature 5° to 40° C (41° to 104° F)
Operating Temperature 0° to 40° C (32° to 104° F)
Operating Time
Approx. 6 hours and 24 minutes (measured
under ideal conditions with the gimbal fully
balanced)
Charging Time
Approx. 1 hour 24 minutes (measured with a
10W USB-C charger)
Gimbal Charging Port USB-C
Power Output Port N/A
Bottom Port 1/4"-20 Screw Hole
Gimbal
Power Consumption
1.1 W (Approximate, measured under ideal
conditions)
Controllable Range
Pan: -95° to 95°
Roll: -100° to 175°
Tilt: -25° to 40°
Mechanical Range
Pan: -161.64° to 173.79°
Roll: -120.30° to 211.97°
Tilt: -101.64° to 78.55°
Max Control Speed 120°/s
Wireless Mode
Model Bluetooth 5.1
Other
App DJI Mimo
Grip Tripod
Dimensions
Length: 138 mm
Diameter: 32 mm
Weight Approx. 72 g

dji OSMO MOBILE 6 Specifications

General

Type	Hand camera stabilizer
Foldable	Yes
Material	-
Pan range	-161.64 - 173.79 °
Product color	Black
Tilt angle range	-101.64 - 78.55 °
Maximum device width	84 mm
Minimum device width	67 mm
Bluetooth version	5.1
Charging time	1.4 h
Operating time	6.4 h
Battery capacity	1000 mAh
Storage temperature (T-T)	5 - 40 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	276 mm
Width	111.5 mm
Height	99 mm
Weight	72 g
Dimensions folded (WxDxH)	84.5 x 189 x 44 mm
