dji OSMO MOBILE 6 User Manual

©
2022 DJI All Rights Reserved.
5
Getting Started
Charging
To charge Osmo Mobile 6, connect a USB adapter (not included) to the charging port
using the power cable. The battery is fully charged when the battery level indicator turns
off on the status panel.
Charging time: approx. 1 hour 24 minutes (tested in the environment temperature of 25° C
when using a 10 W charger)
Max runtime: approx. 6 hours and 24 minutes (tested with the gimbal balanced and held
steadily. This value should be taken as a reference only)
Attaching the Phone
1. Unfold the gimbal as shown. Osmo Mobile 6 will power on automatically once unfolded.
1
2

dji OSMO MOBILE 6 Specifications

General

Type	Hand camera stabilizer
Foldable	Yes
Material	-
Pan range	-161.64 - 173.79 °
Product color	Black
Tilt angle range	-101.64 - 78.55 °
Maximum device width	84 mm
Minimum device width	67 mm
Bluetooth version	5.1
Charging time	1.4 h
Operating time	6.4 h
Battery capacity	1000 mAh
Storage temperature (T-T)	5 - 40 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	276 mm
Width	111.5 mm
Height	99 mm
Weight	72 g
Dimensions folded (WxDxH)	84.5 x 189 x 44 mm
