2. Attach the magnetic phone clamp in the center of the phone. The magnetic phone
clamp can be stretched to adapt to the mobile phone width. The camera mark should
point towards the camera of the phone.
3. Align the marks on the phone clamp and the phone clamp mounting plate. Attach the
mobile phone to Osmo Mobile 6. Osmo Mobile 6 will stabilize once the gimbal mode
indicator lights up on the status panel.
The status indicator on the status panel will pulse red if the magnets are not aligned.
Adjust the position of the magnetic clamp in that case.
The anti-slip pads help to secure the mobile phone and the magnetic phone clamp. Attach
the anti-slip pad to the magnetic phone clamp as shown in the figure below and press
down firmly.
Magnetic Phone Clamp Tips
Make sure the direction of the magnet phone clamp is the same as shown in the figure above.
For optimal performance, make sure the magnetic phone clamp is in the middle of the mobile
phone, and the distance between the clamp arms is the same.

dji OSMO MOBILE 6 Specifications

General

Type	Hand camera stabilizer
Foldable	Yes
Material	-
Pan range	-161.64 - 173.79 °
Product color	Black
Tilt angle range	-101.64 - 78.55 °
Maximum device width	84 mm
Minimum device width	67 mm
Bluetooth version	5.1
Charging time	1.4 h
Operating time	6.4 h
Battery capacity	1000 mAh
Storage temperature (T-T)	5 - 40 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	276 mm
Width	111.5 mm
Height	99 mm
Weight	72 g
Dimensions folded (WxDxH)	84.5 x 189 x 44 mm
