dji Phantom 3 Advanced Operation Manual

Leicester Drones Operations Manual
Copyright © 2016 Leicester Drones Issue 1.2 23 March 2016
Page 11
PART B – AIRCRAFT AND OPERATIONAL CONTROL
7. Aircraft Technical Specifications
The table below shows specifications for aircraft: DJI Phantom 3 Advanced
Item
Aircraft Details
Operators Name / Registered Keeper
Christian Smith
LUASS Registration Number
2165
Manufacturer Name
DJI
Distributor Name
DJI
Airframe Make
DJI
Airframe Model
Phantom 3 Advanced
Serial Number
P76DCD13011171
Airframe Type
Multi-rotor
Span / Diameter (metres)
29cm
Un-laden Weight (kg)
0.8kg
Maximum Take-Off Mass (kg)
1.2kg
Propulsion Type
4 x DJI Brushless Electric Motors
Number of Motors / Engines
4
Motor / Engine Size
2312 960KV
Motor KV
960
Flight Battery Type
DJI LiPro 4S
Flight Battery Capacity
4480mAh
Propeller Size
24cm tip-to-tip
Flight Control System
2.400 GHz – 2.483 GHz
Flight Control System Make & Model
DJI integrated system
Flight Control Serial Number
P80DCD10010210
Flight Control Power Supply
6000mAh LiPo 2S main flight battery
Transmitter Make and Model
DJI GL300a

dji Phantom 3 Advanced Specifications

General

Maximum speed	16 m/s
Frequency band	2.4 - 2.483 GHz
Number of axis	3
GPS (satellite)	Yes
Number of rotors	4 rotors
Maximum flight time	23 min
Maximum ascent speed	5 m/s
Maximum descent speed	3 m/s
Maximum weight capacity	- kg
Maximum operating distance	5000 m
Megapixel	12.4 MP
Video resolutions	1280 x 720, 1920 x 1080, 2704 x 1520 pixels
Maximum frame rate	60 fps
Camera shutter speed	8 - 1/8000 s
Supported video modes	720p, 1080p, 1520p
Video formats supported	AVC, H.264, MOV, MP4, MPEG4
Live view frequency band	2.4 GHz
Maximum video resolution	2704 x 1520 pixels
Field of view (FOV) angle	94 °
Bitrate at maximum video resolution	40 Mbit/s
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	64 GB
Flight modes	Failsafe mode, Follow Me mode
Moving control functions	Backward, Downward, Flying sideways, Forward, Turn left, Turn right, Upward
Battery voltage	15.2 V
Battery capacity	4480 mAh
Transmitter battery capacity	6000 mAh
Number of batteries (transmitter)	1
Product color	White
Operating temperature (T-T)	0 - 40 °C
AC adapter power	57 W
AC adapter output voltage	17.4 V
Equivalent Isotropically Radiated Power (EIRP)	100 dBmW
Motor type	Brushless

Weight and Dimensions

Weight	1280 g
Battery weight	365 g
