Leicester Drones Operations Manual
Copyright © 2016 Leicester Drones Issue 1.2 23 March 2016
Page 20
Severity of Potential Incident or Fatality
1 to 5 = Low Risk
Insignificant
No Incident
1
Non Reportable
Incident
2
Reportable
Incident
3
Major Injury or
Fatalities
4
6 to 10 = Moderate Risk
12 to 15 = High Risk
16 to 20 = Unacceptable Risk
Probability of Hazard
Almost Certain
5
5
10
15
20
Will Probably Occur
4
4
8
12
16
Will Possibly Occur
3
3
6
9
12
Remote Possibility
2
2
4
6
8
Extremely Unlikely
1
1
2
3
4
Risk factors between 1 and 10 are acceptable and the operation can be cleared.
Risk factors between 12 and 15 are unacceptable but mitigating factors may reduce the risk.
Risk factors between 16 and 20 are unacceptable and the operation cannot be cleared.
17. Communications
Contact telephone numbers for the following must be recorded on the On-Site Survey Form which can be
found in Appendix C before embarkation to the site. This task is best carried out at the planning stage whilst
the Pre-Site Survey form is being completed.
Pilot Contact Number
Observer Contact Number
Client Contact Number
Local Police Station Contact Number
Local Hospital Contact Number
Local Air Traffic Control Contact Number
EuroUSC
TM
Contact Number
Consideration must be given to the Operating Location in relation to crew communication. If the operating
location is likely to be busy or noisy then two way radios should be issued so that crew members can remain
in contact. The Pilot-In-Command will not be given a radio as all communication will be relayed through the
Observer so as not to disturb concentration. The Pre-Site Assessment should have already identified any
possible forms of frequency interference, if there is a possible risk then a frequency spectrum analyser
should be used to assess potential interference. All Leicester Drones crew members must carry a fully
charged mobile phone and ensure they have all of the relevant contact numbers in case of emergencies.

Table of Contents

Other manuals for dji Phantom 3 Advanced

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the dji Phantom 3 Advanced and is the answer not in the manual?

dji Phantom 3 Advanced Specifications

General IconGeneral
Maximum speed16 m/s
Frequency band2.4 - 2.483 GHz
Number of axis3
GPS (satellite)Yes
Number of rotors4 rotors
Maximum flight time23 min
Maximum ascent speed5 m/s
Maximum descent speed3 m/s
Maximum weight capacity- kg
Maximum operating distance5000 m
Megapixel12.4 MP
Video resolutions1280 x 720, 1920 x 1080, 2704 x 1520 pixels
Maximum frame rate60 fps
Camera shutter speed8 - 1/8000 s
Supported video modes720p, 1080p, 1520p
Video formats supportedAVC, H.264, MOV, MP4, MPEG4
Live view frequency band2.4 GHz
Maximum video resolution2704 x 1520 pixels
Field of view (FOV) angle94 °
Bitrate at maximum video resolution40 Mbit/s
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size64 GB
Flight modesFailsafe mode, Follow Me mode
Moving control functionsBackward, Downward, Flying sideways, Forward, Turn left, Turn right, Upward
Battery voltage15.2 V
Battery capacity4480 mAh
Transmitter battery capacity6000 mAh
Number of batteries (transmitter)1
Product colorWhite
Operating temperature (T-T)0 - 40 °C
AC adapter power57 W
AC adapter output voltage17.4 V
Equivalent Isotropically Radiated Power (EIRP)100 dBmW
Motor typeBrushless
Weight and Dimensions IconWeight and Dimensions
Weight1280 g
Battery weight365 g
