dji Phantom 3 Advanced Operation Manual

Leicester Drones Operations Manual
Copyright © 2016 Leicester Drones Issue 1.2 23 March 2016
Page 12
7.1. Operating Limitations and Conditions
The table below shows aircraft operational limitations;
Receiver Make & Model
DJI Integrated System
Aircraft Control Frequency & Power
Output
2.4GHz @ 100mW
GPS Unit
DJI Integrated System
Inertial Measuring Unit
DJI Integrated System
Ground Station Type
Active
Ground Station Make and Model
IPad Mini
Telemetry Link Make, Model,
Frequency & Power Output
DJI “Lightbridge” system on 2.4GHz @
100mW
Payload Link Make, Model, Frequency
& Power Output
DJI “Lightbridge” System on 2.4GHz @
100mW
Software / Firmware Version
V1.6.0040
Limitation
DJI Phantom 3 Advanced
Operational Ceiling
4,800ft Above Mean Sea Level (AMSL)
Operational Endurance
20 Minutes
Maximum Permissible Airspeed
20 Knots Airspeed
Maximum Outside Air Temperature
40°C
Minimum Outside Air Temperature
0°C
Maximum Permissible Wind Speed Including
Gusts
15 Kts @ 0ft Above Ground Level
(AGL)
Frequencies Used
2.400GHz @ 100mW
Centre of Gravity
Marked with a sticker on bottom of
gimbal
Balance Limitations
15mm fore and aft of the balance
point

dji Phantom 3 Advanced Specifications

General

Maximum speed	16 m/s
Frequency band	2.4 - 2.483 GHz
Number of axis	3
GPS (satellite)	Yes
Number of rotors	4 rotors
Maximum flight time	23 min
Maximum ascent speed	5 m/s
Maximum descent speed	3 m/s
Maximum weight capacity	- kg
Maximum operating distance	5000 m
Megapixel	12.4 MP
Video resolutions	1280 x 720, 1920 x 1080, 2704 x 1520 pixels
Maximum frame rate	60 fps
Camera shutter speed	8 - 1/8000 s
Supported video modes	720p, 1080p, 1520p
Video formats supported	AVC, H.264, MOV, MP4, MPEG4
Live view frequency band	2.4 GHz
Maximum video resolution	2704 x 1520 pixels
Field of view (FOV) angle	94 °
Bitrate at maximum video resolution	40 Mbit/s
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	64 GB
Flight modes	Failsafe mode, Follow Me mode
Moving control functions	Backward, Downward, Flying sideways, Forward, Turn left, Turn right, Upward
Battery voltage	15.2 V
Battery capacity	4480 mAh
Transmitter battery capacity	6000 mAh
Number of batteries (transmitter)	1
Product color	White
Operating temperature (T-T)	0 - 40 °C
AC adapter power	57 W
AC adapter output voltage	17.4 V
Equivalent Isotropically Radiated Power (EIRP)	100 dBmW
Motor type	Brushless

Weight and Dimensions

Weight	1280 g
Battery weight	365 g
