dji Phantom 3 Advanced Operation Manual

Leicester Drones Operations Manual
Copyright © 2016 Leicester Drones Issue 1.2 23 March 2016
Page 34
Pre-Site Assessment Form
SITE NAME
JOB NUMBER
DATE
LATITUDE & LONGITUDE:
ft
TEAM
PILOT IN COMMAND:
OBSERVER: VEHICULAR ACCESS: YES NO
UAV REGISTRATION:
HELPER 1:
HELPER 2:
LOCATION
ITEM ACTION
(Use skydem on light, google earth & m etcheck)
FINDING
AIRSPACE What is the Airspace? (A,C,D,E,F,G) - Do I need ATC permission?
TERRAIN What is the Terrain? (Flat, Mountainous, Boggy)
PROXIMITIES Other Aircraft (Aerodromes, Heli Pads, Model Sites)
HAZARDS
Live Firing, High Intensity Radio Transmissions, Gas Venting
RESTRICTIONS Nuclear Power Stations, Prisons
SENSITIVITIES Nature Reserves, Recreational Areas, Bye Laws
PEOPLE Local Habitation (Do we need to Letter Drop)
LIVESTOCK Local Farms
PERMISSION Local Authority, Land Owner, Military Space
ACCESS Public Right of Way, Gates & Roads
FOOTPATHS
Public Footpaths, Bridal Paths
ALTERNATE Alternative Operational / Take Off Sites
RISK REDUCTION
Can the job be done at another time to avoid School times etc
WEATHER 24 hour forecast
NOTAMS Any Notice to Airmen that may effect operations
PRE NOTIFICATIONS
If Notified Date, Time & Contact Name
LOCAL AIR TRAFFIC CONTROL:
REGIONAL AIR TRAFFIC CONTROL:
MILITARY CONTROL:
NOTICE TO AIRMEN:
PRE SITE SURVEY
DOWLOADED MAP TO GROUNDSTATION: (Tick)
ALTITUTUDE FROM SEA LEVEL:
WORK REQUIRED:
DATE WORK REQUIRED:

dji Phantom 3 Advanced Specifications

General

Maximum speed	16 m/s
Frequency band	2.4 - 2.483 GHz
Number of axis	3
GPS (satellite)	Yes
Number of rotors	4 rotors
Maximum flight time	23 min
Maximum ascent speed	5 m/s
Maximum descent speed	3 m/s
Maximum weight capacity	- kg
Maximum operating distance	5000 m
Megapixel	12.4 MP
Video resolutions	1280 x 720, 1920 x 1080, 2704 x 1520 pixels
Maximum frame rate	60 fps
Camera shutter speed	8 - 1/8000 s
Supported video modes	720p, 1080p, 1520p
Video formats supported	AVC, H.264, MOV, MP4, MPEG4
Live view frequency band	2.4 GHz
Maximum video resolution	2704 x 1520 pixels
Field of view (FOV) angle	94 °
Bitrate at maximum video resolution	40 Mbit/s
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	64 GB
Flight modes	Failsafe mode, Follow Me mode
Moving control functions	Backward, Downward, Flying sideways, Forward, Turn left, Turn right, Upward
Battery voltage	15.2 V
Battery capacity	4480 mAh
Transmitter battery capacity	6000 mAh
Number of batteries (transmitter)	1
Product color	White
Operating temperature (T-T)	0 - 40 °C
AC adapter power	57 W
AC adapter output voltage	17.4 V
Equivalent Isotropically Radiated Power (EIRP)	100 dBmW
Motor type	Brushless

Weight and Dimensions

Weight	1280 g
Battery weight	365 g
