Leicester Drones Operations Manual
Copyright © 2016 Leicester Drones Issue 1.2 23 March 2016
Page 15
then an investigation should be initiated to identify the cause and consider implementing steps to
reduce the likelihood of this incident occurring again.
All MAJOR incidents require an investigation as outlined in the Investigation Procedure section and the
Incident Logbook should be completed.
10.3. Investigation Procedure
Any investigations undertaken by Leicester Drones will follow the procedure shown below. EuroUSC
TM
will be advised initially of any occurrence with a simple statement of the known facts such as date, time,
location, aircraft involved, Pilot-In-Command, damage sustained and a brief description of the
occurrence. EuroUSC
TM
will also then receive a copy of the final investigation report once completed.
INTRODUCTION
The introduction contains the context for the Incident and confirms the major facts as to the companies
and people involved, why they were present and the reason for the flights being carried out.
DESCRIPTION OF EVENTS
This is a factual account of the events leading up to and immediately after the incident as well as the
incident itself. Its aim is to provide an agreed basis upon which the analysis is carried out.
Importantly any assumptions should be clearly stated and all data provided should have its authenticity
and derivation stated. If there are doubts then these should also be clearly articulated so that future
analysis can take this into account.
ANALYSIS
The analysis of events sets out to find explanations for what is described in the description of events.
Wherever possible the analysis draws upon known concepts, models and physical understanding to
ensure that the events as described have a logical explanation.
The analysis should set the scene for any conclusions and provide traceability from the facts to the
conclusions in a logical and auditable way.
CONCLUSIONS
The conclusions are derived from the analysis, which themselves are based upon the facts in the
description of events or the facts as they pertain to concepts, models and physical understanding
exposed within the analysis. A strong conclusion is one where this traceability is good and can stand up
to scrutiny.
RECOMMENDATIONS
The aim of the recommendations is to provide the organisations or personnel identified for the report
with those items and actions that can lead to a safer operation and which address the short-comings
highlighted through the investigation process. These may cover anything, however the key issue of
safety must be addressed and is the primary concern of EuroUSC
TM
.
10.4. Mandatory Occurrence Reporting
Mandatory Occurrence Reporting will be completed as required by the National Aviation Authority for
the particular country of operation. For example, when operating in the United Kingdom CAP382 will be
the compliance document and reporting will be carried out utilising the form SRG 1601.

Table of Contents

Other manuals for dji Phantom 3 Advanced

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the dji Phantom 3 Advanced and is the answer not in the manual?

dji Phantom 3 Advanced Specifications

General IconGeneral
Maximum speed16 m/s
Frequency band2.4 - 2.483 GHz
Number of axis3
GPS (satellite)Yes
Number of rotors4 rotors
Maximum flight time23 min
Maximum ascent speed5 m/s
Maximum descent speed3 m/s
Maximum weight capacity- kg
Maximum operating distance5000 m
Megapixel12.4 MP
Video resolutions1280 x 720, 1920 x 1080, 2704 x 1520 pixels
Maximum frame rate60 fps
Camera shutter speed8 - 1/8000 s
Supported video modes720p, 1080p, 1520p
Video formats supportedAVC, H.264, MOV, MP4, MPEG4
Live view frequency band2.4 GHz
Maximum video resolution2704 x 1520 pixels
Field of view (FOV) angle94 °
Bitrate at maximum video resolution40 Mbit/s
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size64 GB
Flight modesFailsafe mode, Follow Me mode
Moving control functionsBackward, Downward, Flying sideways, Forward, Turn left, Turn right, Upward
Battery voltage15.2 V
Battery capacity4480 mAh
Transmitter battery capacity6000 mAh
Number of batteries (transmitter)1
Product colorWhite
Operating temperature (T-T)0 - 40 °C
AC adapter power57 W
AC adapter output voltage17.4 V
Equivalent Isotropically Radiated Power (EIRP)100 dBmW
Motor typeBrushless
Weight and Dimensions IconWeight and Dimensions
Weight1280 g
Battery weight365 g
