Gimbal Camera

Phantom 3 Advanced

User Manual

Camera Operation

Use the Shutter and Video Recording buttons on the remote controller to shoot the images or videos

through the DJI GO app. For more information about how to use these buttons, refer to “Controlling the

Camera Page 24”.

Camera LED Indicator

Camera LED Indicator lights up after the flight battery is powered on. It provides information on the

working status of the camera.

Camera LED Indicator Camera status

Green Fast Blink (0.2s off, 0.1s on ) System is warming up.

Green Blink Once (0.5s off, 0.4s on ) Taking a single picture.

Green Blink 3 Times (0.3s off, 0.1s on ) Taking 3 or 5 photos per shot.

Slow Red Blink (1.6s on, 0.8s off ) Recording.

Fast Red Blink (0.5s off, 0.2s on ) SD card error.

Double Red Blink (0.1s on, 0.1s off, 0.1s on, 0.1s off) Overheated Camera

Solid Red System error.

Green and Red Blink (0.8s green on, 0.8s red on) Firmware Upgrading

Gimbal

Gimbal Prole

The 3-axis gimbal provides a steady platform for the attached camera, allowing you to capture clear,

stable images and video. The gimbal can tilt the camera within a 120˚ range.

-90°

0°

30°

Use the gimbal dial on the remote controller to control the tilt movement of the camera.

Other manuals for dji PHANTOM 3

Questions and Answers:

Need help?

Do you have a question about the dji PHANTOM 3 and is the answer not in the manual?

General

Max Flight Time	23 minutes
Battery Capacity	4480 mAh
Weight	1280 g (Including battery and propellers)
Max Ascent Speed	5 m/s
Max Descent Speed	3 m/s
Max Service Ceiling Above Sea Level	6000 m
GPS Mode	GPS/GLONASS
Battery Voltage	15.2 V
Battery Type	LiPo 4S
Max Charging Power	100 W
Lens FOV	94°
Aperture	f/2.8
Shutter Speed	8s -1/8000s
Max Image Resolution	4000 x 3000
Max Bitrate	40 Mbps
Max Speed	16 m/s (ATTI mode, no wind)
Video Resolution	2.7K: 2704x1520p 24/25/30 (29.97); FHD: 1920x1080p 24/25/30/48/50/60
Operating Temperature	0°C to 40°C
Transmitter Power (EIRP)	20 dBm (FCC), 14 dBm (CE)
Video Recording Modes	2.7K, FHD
Camera Sensor	1/2.3" CMOS
ISO Range	100-3200 (video), 100-1600 (photo)
Photo Formats	JPEG, DNG
Video Formats	MP4/MOV (H.264)
Remote Controller Operating Frequency	2.4 GHz
Mobile Device Holder	For mobile phones or tablets
Hover Accuracy Range	Vertical: +/- 0.5 m; Horizontal: +/- 1.5 m
