dji RC Plus User Manual

12
©
2023 DJI All Rights Reserved.
Remote Controller Operations
Charging the Battery
The internal battery will be placed in hibernation mode before delivery. It must be charged before rst-
time use. The battery level LEDs will start to ash to indicate that the internal battery is activated.
It takes approximately 2 hours to fully charge the remote controller internal battery using a
recommended charging device.
Charging time for a WB37 battery (if installed) with 0% power:
a. When it is mounted on the remote controller and the internal battery power is 0%: approximately
2 hours (the internal battery will be fully charged simultaneously)
b. When it is mounted on the remote controller and the internal battery power is 100%:
approximately 1 hour and 10 minutes
For optimal charging, it is recommended to use the charging device from the compatible aircraft or a
certied USB-C charger with a maximum rated power of 65W and a maximum voltage of 20V, such
as the DJI 65W Portable Charger.
Fully discharge and charge the remote controller every three months. The battery depletes when
stored for an extended period.
Checking the Battery Level
Press the power button once to check the current battery level.
Low
High
5-20 V

dji RC Plus Specifications

General

Screen Size	7 inches
Brightness	1200 cd/m²
Wi-Fi Protocol	802.11 a/b/g/n/ac
Bluetooth Operating Frequency	2.4 GHz
Video Output Port	HDMI
Operating System	Android
Screen Resolution	1920 x 1200
Operating Temperature	-20° to 45° C (-4° to 113° F)
Connectivity	USB-C, HDMI
Wi-Fi Operating Frequency	2.4 GHz, 5.8 GHz
Operating Frequency	2.400-2.4835 GHz; 5.725-5.850 GHz
Max Transmission Distance	15 km
GNSS	BeiDou
Charging Time	Approximately 2 hours
Compatibility	DJI Matrice 30 Series
Battery Life	Approx. 6 hours
