dji RC Plus User Manual

DJI RC Plus User Manual
22
©
2023 DJI All Rights Reserved.
Screen Gestures
Slide up from the bottom of
the screen and hold to access
recently opened apps.
Slide from the left or right to
the center of the screen to
return to the previous screen.
Slide up from the bottom of
the screen to return to the
home screen.

dji RC Plus Specifications

General

Screen Size	7 inches
Brightness	1200 cd/m²
Wi-Fi Protocol	802.11 a/b/g/n/ac
Bluetooth Operating Frequency	2.4 GHz
Video Output Port	HDMI
Operating System	Android
Screen Resolution	1920 x 1200
Operating Temperature	-20° to 45° C (-4° to 113° F)
Connectivity	USB-C, HDMI
Wi-Fi Operating Frequency	2.4 GHz, 5.8 GHz
Operating Frequency	2.400-2.4835 GHz; 5.725-5.850 GHz
Max Transmission Distance	15 km
GNSS	BeiDou
Charging Time	Approximately 2 hours
Compatibility	DJI Matrice 30 Series
Battery Life	Approx. 6 hours
