dji RC Plus User Manual

DJI RC Plus User Manual
14
©
2023 DJI All Rights Reserved.
2. Run DJI Pilot 2 and tap Link Remote Controller to link. The status LED of the remote controller will
blink blue, and the remote controller will beep during linking.
3. Press and hold the power button on the aircraft for at least ve seconds. The aircraft power indicator
will blink and will beep twice to indicate linking has started. When linking is successful, the aircraft
rear indicators will blink green while the remote controller will beep twice, and the remote controller
status LEDs will turn solid green.
Make sure the remote controller is within 50cm (1.6ft) of the aircraft during linking.
Make sure the remote controller is connected to the internet when logging in using a DJI account.

dji RC Plus Specifications

General

Screen Size	7 inches
Brightness	1200 cd/m²
Wi-Fi Protocol	802.11 a/b/g/n/ac
Bluetooth Operating Frequency	2.4 GHz
Video Output Port	HDMI
Operating System	Android
Screen Resolution	1920 x 1200
Operating Temperature	-20° to 45° C (-4° to 113° F)
Connectivity	USB-C, HDMI
Wi-Fi Operating Frequency	2.4 GHz, 5.8 GHz
Operating Frequency	2.400-2.4835 GHz; 5.725-5.850 GHz
Max Transmission Distance	15 km
GNSS	BeiDou
Charging Time	Approximately 2 hours
Compatibility	DJI Matrice 30 Series
Battery Life	Approx. 6 hours
